.干式轴封,可保护马达防止酸气进入损坏培林,提高马达使用寿命.
.泵浦可无水完运转使用,绝不会损坏.
.适合各种槽外、槽内酸碱液体循环,适用于冷却、喷洗、蚀刻及废水处理等制程.
型号说明
HTD-40-SK-1-5-V-F-4
1. 机型编号Model:HD
2. 出口口径Outlet:40:1-1/2”,50:2”,65:2-1/2”,100:4”
3. 比重Sp:SK-1.1,SP-1.4
4. 功率Power:1-1HP,2-2HP,3-3HP,5-5HP,7.5-7.5HP,10-10HP
5. 频率Frequency：5:50HZ,6:60HZ
6. 橡胶材质Rubber:N-NBR,E-EPDM,V-VITON
7. 泵体材质Pump Material:F-FRPP,C-CFRPP,P-PVDF
8. 轴心材质Axis Material:4-SUS304,6-SUS316,T-TI
规格表(测试流体:水 比重1.0)
|
规格 |
曲线 |
比重 |
入口 Inlet (mm) |
出口 Outlet (mm)
|
50HZ |
60HZ |
马力 Power HP |
重量 KG |
|||
|
全扬程 M |
全流量 L/min |
全扬程 M |
全流量 L/min |
||||||||
|
50HZ |
60HZ |
||||||||||
|
HTD-40SK-1 |
A |
a |
1.1 |
50 |
40 |
14 |
280 |
13 |
240 |
1 |
29 |
|
HTD-40SK-2 |
B |
b |
1.1 |
50 |
40 |
18 |
400 |
22 |
330 |
2 |
38 |
|
HTD-40SK-3 |
C |
c |
1.1 |
50 |
40 |
20 |
440 |
26 |
440 |
3 |
41 |
|
HTD-50SK-3 |
D |
d |
1.1 |
65 |
50 |
21 |
530 |
23 |
510 |
3 |
41 |
|
HTD-50SK-5 |
E |
e |
1.1 |
65 |
50 |
31 |
580 |
36 |
560 |
5 |
55 |
|
HTD-65SK-5 |
F |
f |
1.1 |
80 |
65 |
29 |
630 |
29 |
620 |
5 |
55 |
|
HTD-65SK-7.5 |
G |
g |
1.1 |
80 |
65 |
34 |
730 |
37 |
920 |
7.5 |
95 |
|
HTD-65SK-10 |
H |
h |
1.1 |
80 |
65 |
37 |
760 |
39 |
1020 |
10 |
106 |
|
HTD-100SK-15 |
I |
i |
1.1 |
100 |
100 |
38 |
1760 |
36 |
1800 |
15 |
115 |
|
HTD-40SP-3 |
C |
c |
1.4 |
50 |
40 |
22 |
400 |
22 |
340 |
3 |
41 |
|
HTD-50SP-3 |
D |
d |
1.4 |
65 |
50 |
19 |
520 |
20 |
400 |
3 |
41 |
|
HTD-50SP-5 |
E |
e |
1.4 |
65 |
50 |
28 |
600 |
29 |
500 |
5 |
55 |
|
HTD-65SP-5 |
F |
f |
1.4 |
80 |
65 |
27 |
520 |
27 |
600 |
5 |
55 |
|
HTD-65SP-7.5 |
G |
g |
1.4 |
80 |
65 |
31 |
720 |
32 |
750 |
7.5 |
95 |
|
HTD-65SP-10 |
H |
h |
1.4 |
80 |
65 |
33 |
750 |
33 |
850 |
10 |
106 |
|
HTD-100SP-15 |
I |
i |
1.4 |
100 |
100 |
38 |
1680 |
35 |
1860 |
15 |
115 |
