天津启隆机电设备有限公司特价销售经销丹麦卡姆鲁普kamstrup卡姆鲁普kamstrup电表，卡姆鲁普kamstrup电流表，卡姆鲁普kamstrup热能表，卡姆鲁普kamstrup水表，卡姆鲁普kamstrup智能表等产品。

丹麦卡姆鲁普kamstrup公司是世界领先的智能能量表和水表计费系统解决方案供应商。

KAMSTRUP卡姆鲁普主要系列型号

ULTRAFLOW 54

MULTICAL 21/flowIQ 21xx

flowIQ 3100

flowIQ 2200

MULTICAL 62

MAG8000

MULTICAL 302

MULTICAL 403

MULTICAL 603

MULTICAL 801

MULTICAL 6M2

KAMSTRUP MULTICAL 62 WATER METER

65-2-CDAA-xxx    kamstrup 62.½” Water Meter Q3 1.6 m³/h PN 16   110mm

65-2-CDA1-xxx    Kamstrup 62.¾” Water Meter Q3 1.6 m³/h PN 16 110mm

65-2-CDAC-xxx    Kamstrup 62.½” Water Meter Q3 1.6 m³/h PN 16* 165mm

65-2-CDAF-xxx    Kamstrup 62.¾” Water Meter Q3 1.6 m³/h PN 16 190mm

65-2-CEAF-xxx     Kamstrup 62.¾” Water Meter Q3 2.5 m³/h PN 16 190mm

65-2-CGAG-xxx    Kamstrup 62.1” Water Meter Q3 4.0 m³/h PN 16   260mm

65-2-CHAG-xxx   Kamstrup 62.1” Water Meter Q3 6.3 m³/h PN 16   260mm

65-2-CJAJ-xxx      Kamstrup 62. 1.½ ” Water Meter Q3 10.0 m³/h PN 16 300mm

65-2-CKCE-xxx    Kamstrup 62. DN50 Water Meter Q3 16.0 m³/h PN 25   270mm

65-2-CLCG-xxx    Kamstrup 62. DN65 Water Meter Q3 25.0 m³/h PN 25   300mm

65-2-CMCH-xxx   Kamstrup 62. DN80 Water Meter Q3 40.0 m³/h PN 25   300mm

KAMSTRUPSTRUP       MULTICAL 21 ULTRASonIC HOT WATER METER

021-46-C0A-7XX Kamstrup 21.½” Hot Water Meter Q3 1.6 m³/h PN16    110mm

021-46-C0D-7XX Kamstrup 21.½” Hot Water Meter Q3 2.5 m³/h PN16    110mm

021-46-C0G-7XX Kamstrup 21.¾” Hot Water Meter Q3 2.5 m³/h PN16    105mm

021-46-C0H-7XX Kamstrup 21.¾” Hot Water Meter Q3 2.5 m³/h PN16    130mm

021-46-C0E-7XX Kamstrup 21.¾” Hot Water Meter Q3 2.5 m3/h PN16   190mm

021-46-C0L-7XX Kamstrup 21.¾” Hot Water Meter Q3 4.0 m³/h PN16    130mm

021-46-C0N-7XX Kamstrup 21.¾” Hot Water Meter Q3 4.0 m3/h PN16   190mm

KAMSTRUPSTRUP MULTICAL 21 ULTRASonIC COLD WATER METER

021-46-C0A-8XX Kamstrup 21.½” Cold Water Meter Q3 1.6 m³/h PN16 110mm

021-46-C0D-8XX Kamstrup 21.½” Cold Water Meter Q3 2.5 m³/h PN16 110mm

021-46-C0G-8XX Kamstrup 21.¾” Cold Water Meter Q3 2.5 m³/h PN16 105mm

021-46-C0H-8XX Kamstrup 21.¾” Cold Water Meter Q3 2.5 m³/h PN16 130mm

021-46-C0E-8XX Kamstrup 21.¾” Cold Water Meter Q3 2.5 m3/h PN16 190mm

021-46-C0L-8XX Kamstrup 21.¾” Cold Water Meter Q3 4.0 m³/h PN16 130mm

021-46-C0N-8XX Kamstrup 21.¾” Cold Water Meter Q3 4.0 m3/h PN16 190mm

KAMSTRUPSTRUP 801 base MODULE

KAMSTRUP 801. M-Bus module + 2 pulse inputs (VA, VB)

67002100      KAMSTRUP 801. RadioRouter module + 2 pulse inputs (VA, VB)*

67002200      KAMSTRUP 801. Prog. data logger + RTC + 4…20 mA inputs + 2 pulse inputs (VA, VB)

67002400      KAMSTRUP 801. LonWorks module + 2 pulse inputs (VA, VB)***

67002700      KAMSTRUP 801. M-Bus module with alternative registers + 2 pulse inputs (VA, VB)

67002900      KAMSTRUP 801. M-Bus module with MULTICAL® III compatible data + 2 pulse inputs (VA, VB)

67003000      KAMSTRUP 801. Wireless M-Bus, C1, standard registers, encrypted, 868 MHz, internal and external antenna + 2 pulse inputs (VA, VB)

67003100      KAMSTRUP 801. Wireless M-Bus, T1 OMS, encrypted, 868 MHz, internal and external antennas

67003500      KAMSTRUP 801. Wireless M-Bus, C1, alternative registers, encrypted, 868 MHz, internal and external antenna + 2 pulse inputs (VA, VB)

67003800      KAMSTRUP 801. Wireless M-Bus, C1, encrypted, 868 MHz, internal and external antennas, fixed networks

67006000      KAMSTRUP 801. ZigBee 2.4 GHz with internal antenna + 2 pulse inputs (VA, VB)

67006200      KAMSTRUP 801. metasys N2 (RS-485) + 2 pulse inputs (VA, VB)***

67006400      KAMSTRUP 801. SIOX module (Auto detect Baud rate)

67006600      KAMSTRUP 801. BACnet MS/TP module (RS-485) + 2 pulse inputs (VA, VB)***

67006700      KAMSTRUP 801. Modbus RTU module (RS-485) + 2 pulse inputs (VA, VB)***

67008400      KAMSTRUP 801. High Power RadioRouter + 2 pulse inputs (VA, VB) *

16-40-080     KAMSTRUP 801. Module connector

KAMSTRUPSTRUP 801 TOP MODULE

670M KAMSTRUP 801. SIOX module (Auto detect Baud rate)

670P       KAMSTRUP 801. M-Bus module with alternative registers

670Q      KAMSTRUP 801. M-Bus module with MULTICAL® III compatible data

670U      KAMSTRUP 801. 3G GSM/GPRS module (GSM 8H 3G)*

670V      KAMSTRUP 801. M-Bus module

670W KAMSTRUP 801. RadioRouter module**

670Y       KAMSTRUP 801. LonWorks module

670Z       KAMSTRUP 801. GSM6H module excl. external antenn**

16-40-080     KAMSTRUP 801. Module connector

KAMSTRUPSTRUP 801 POWER SUPPLY

66-99-622     230 VAC for MULTICAL® 801 with GSM or High Power Radio Router

66-99-634     24 VAC for MULTICAL® 801 with GSM or High Power Radio Router

KAMSTRUPSTRUP 801 SENSOR FITTINGS

65-57-324     65mm x ½ sensor pocket,stainless steel for 5.8mm

65-57-327     90mm x ½ sensor pocket,stainless steel for 5.8mm

65-57-314     140mm x ½ sensor pocket,stainless steel for 5.8mm

KAMSTRUPSTRUP 801 TEMPERATURE SENSOR SET PT500

6700000A      Set of pocket sensors with 1.5m cable 5.8mm dia

6700000B      Set of pocket sensors with 3.0m cable 5.8mm dia

6700000C      Set of pocket sensors with 5.0m cable 5.8mm dia

6700000D      Set of pocket sensors with 10m cable 5.8mm dia

6700000F       Set of pocket sensors with short probe 1.5m cable

6700000G      Set of pocket sensors with short probe 3.0m cable

KAMSTRUPSTRUP 602 FLANGED ConNECTION – PN25

65-5-CDCA   Kamstrup 602. DN20 Heat Meter qp 1.5 m³/h PN25      190mm

65-5-CECA    Kamstrup 602. DN20 Heat Meter qp 2.5 m³/h PN25      190mm

65-5-CGCB   Kamstrup 602. DN25 Heat Meter qp 3.5 m³/h PN25      260mm

65-5-CHCB   Kamstrup 602. DN25 Heat Meter qp 6.0 m³/h PN25      260mm

65-5-CHCC   Kamstrup 602. DN32 Heat Meter qp 6.0 m³/h PN25      260mm

65-5-CJCD    Kamstrup 602. DN40 Heat Meter qp 10.0 m³/h PN25    300mm

65-5-CKCE    Kamstrup 602. DN50 Heat Meter qp 15.0 m³/h PN25    270mm

65-5-CLCG    Kamstrup 602. DN65 Heat Meter qp 25.0 m³/h PN25    300mm

65-5-CMCH Kamstrup 602. DN80 Heat Meter qp 40.0 m³/h PN25    300mm

65-5-FACL    Kamstrup 602. DN100 Heat Meter qp 60 m³/h PN25     360mm

65-5-FBCL    Kamstrup 602. DN100 Heat Meter qp 100 m³/h PN25   360mm

665-5-FBCM Kamstrup 602. DN125 Heat Meter qp 100 m³/h PN25   350mm

65-5-FCCN-10     Kamstrup 602. DN150 Heat Meter qp 150 m³/h PN25   500mm

65-5-FDCN-10     Kamstrup 602. DN150 Heat Meter qp 250 m³/h PN25   500mm

65-5-FECN-10     Kamstrup 602. DN150 Heat Meter qp 400 m³/h PN25   500mm

65-5-FECP-10      Kamstrup 602. DN250 Heat Meter qp 400 m³/h PN25   500mm

65-5-FECR-10      Kamstrup 602. DN250 Heat Meter qp 400 m³/h PN25   600mm

65-5-FFCP-10      Kamstrup 602. DN200 Heat Meter qp 600 m³/h PN25   500mm

65-5-FFCP-10      Kamstrup 602. DN200 Heat Meter qp 600 m³/h PN25   500mm

65-5-FFCR-10      Kamstrup 602. DN250 Heat Meter qp 600 m³/h PN25   600mm

65-5-FGCR-10     Kamstrup 602. DN250 Heat Meter qp 1000 m³/h PN25 600mm

65-5-FGDS-10     Kamstrup 602. DN300 Heat Meter qp 1000 m³/h PN16 500mm

KAMSTRUPSTRUP MULTICAL® 302 HEAT METER

302Q910 Kamstrup 302. ½” BSP Heat Meter Qp 0.6m³/h, PN16/25    110mm

302Q911 Kamstrup 302. ½” BSP Heat Meter Qp 0.6m³/h, PN16/25    130mm

302Q912 Kamstrup 302. ½” BSP Heat Meter Qp 0.6m³/h, PN16/25    165mm

302Q940 Kamstrup 302. ½” BSP Heat Meter Qp 1.5m³/h, PN16/25    110mm

302Q941 Kamstrup 302. ½” BSP Heat Meter Qp 1.5m³/h, PN16/25    130mm

302Q942 Kamstrup 302. ½” BSP Heat Meter Qp 1.5m³/h, PN16/25    165mm

302Q970 Kamstrup 302. ¾” BSP Heat Meter Qp 1.5m³/h, PN16/25    130mm

302Q971 Kamstrup 302. ¾” BSP Heat Meter Qp 1.5m³/h, PN16/25    190mm

302Q972 Kamstrup 302. ¾” BSP Heat Meter Qp 1.5m³/h, PN16/25    2200mm

302Q9A0       Kamstrup 302. ¾” BSP Heat Meter Qp 2.5m³/h, PN16/25    130mm

302Q9A1       Kamstrup 302. ¾” BSP Heat Meter Qp 2.5m³/h, PN16/25    190mm

302Q9A2       Kamstrup 302. ¾” BSP Heat Meter Qp 2.5m³/h, PN16/25    220mm

30-26-655.A Kamstrup 302. Wall Bracket

31-30-262     Kamstrup 302. Blind plug for temperature sensor in flow sensor

59-20-257     Kamstrup 302. G ½” ball valve with M10x1 sensor pocket

59-20-271     Kamstrup 302. G ¾” ball valve with M10x1 sensor pocket

65-61-346     Kamstrup 302. Holder for optical reading head

302T20 Kamstrup 302. Mbus card c/w 1.5mtr cable

302T21 Kamstrup 302. Mbus card c/w 2.5mtr cable

302T30 Kamstrup 302. Wireless Mbus 868MHz

3021       Kamstrup 302. 6 Year Battery Normal Response

302 Kamstrup 302. 12 Year Battery Normal Response

3023       Kamstrup 302. 6 Year Battery Fast Response

KAMSTRUPSTRUP M-BUS MASTER MULTIPORT 250D

KAMSTRUPSTRUP 801 INDUSTRIAL CALCULATOR FOR HEAT

67-F       Calculator PT100 4 wire with no analog outputs

67-G      Calculator PT100 4 wire with no analog outputs

67-K       Calculator PT100 4 wire with analog outputs

67-L       Calculator PT100 4 wire with analog outputs

6700000A      Pair of temp sensors PT500 1.5m

6700000B      Pair of temp sensors PT500 3.0m

6700000C      Pair of temp sensors PT500 5.0m

6700000D      Pair of temp sensors PT500 10.0m

KAMSTRUPSTRUP USB METER READER

KAMSTRUPSTRUP 602 INDUSTRIAL CALCULATOR FOR HEAT

602-A Calculator PT100 2 wire for ultraflow or pulsed water meter

602-B Calculator PT500 4 wire for ultraflow or pulsed water meter

602-C Calculator PT500 2 wire for ultraflow or pulsed water meter

602-D Calculator PT500 4 wire for 24v AC active pulses

6700000A      Pair of temp sensors PT500 1.5m

6700000B      Pair of temp sensors PT500 3.0m

6700000C      Pair of temp sensors PT500 5.0m

670000D Pair of temp sensors PT500 10.0m

1606064 D Cell battery with connector

60200007      230v AC power supply

60200008      24v AC power supply

MULTICAL 402 PT500 TEMPERATURE SENSORS

Pocket Temp sensor set with 1.5m cable 40200000A

Pocket Temp sensor set with 3.0m cable 40200000B

Short direct Temp sensor set with 1.5m cable 40200000F

Short direct Temp sensor set with 3m cable 40200000G

801 COMMUNICATION MODULES

Description

M-Bus module 670V

Radio Router module 670W

LonWorks module FTT-10A 670Y

GSM6H module excl external antenna 670Z

M-Bus module with pulse inputs 670020

Radio Router module with pulse inputs – require external supply 670021

Prog data logger RTC 4-20 Ma inputs and pulse inputs-require external supply 670022

Lon works module FTT-10A with pulse inputs – require external supply 670024

602 base MODULES

67001000      Kamstrup 602. Data output + 2 pulse inputs (VA, VB)

67002000      Kamstrup 602. M-Bus module + 2 pulse inputs (VA, VB)

67002200      Kamstrup 602. Prog. data logger + RTC + 4…20 mA inputs + 2 pulse inputs (VA, VB)

67002300      Kamstrup 602. Analog 0/4…20 mA outputs **

67002400      Kamstrup 602. LonWorks module + 2 pulse inputs (VA, VB)**

67002500      Kamstrup 602. Radio module + 2 pulse inputs (VA, VB)

67002700      Kamstrup 602. M-Bus module with alternative registers + 2 pulse inputs (VA, VB)

67002800      Kamstrup 602. M-Bus module with medium data package + 2 pulse inputs (VA, VB)

67002900      Kamstrup 602. M-Bus module with MULTICAL® III compatible data + 2 pulse inputs (VA, VB)

60200300      Kamstrup 602. Wireless M-Bus, C1, standard registers, encrypted, 868 MHz, internal and external antenna + 2 pulse inputs (VA, VB)

67003100      Kamstrup 602. Wireless M-Bus, T1 OMS, encrypted, 868 MHz, internal and external antennas

60200350      Kamstrup 602. Wireless M-Bus, C1, alternative registers, encrypted, 868 MHz, internal and external antenna + 2 pulse inputs (VA, VB)

60200360      Kamstrup 602. Wireless M-Bus, T1 OMS short interval, encrypted, 868 MHz, internal and external antennas

60200380      Kamstrup 602. Wireless M-Bus, C1, encrypted, 868 MHz, internal and external antennas, fixed network

67006000      Kamstrup 602. ZigBee 2.4 GHz with internal antenna + 2 pulse inputs (VA, VB)

67006200      Kamstrup 602. metasys N2 (RS-485) + 2 pulse inputs (VA, VB)**

67006400      Kamstrup 602. SIOX module (Auto detect Baud rate)

67006600      Kamstrup 602. BACnet MS/TP module (RS-485) + 2 pulse inputs (VA, VB)**

67006700      Kamstrup 602. Modbus RTU module (RS-485) + 2 pulse inputs (VA, VB)**

60200800      Kamstrup 602. GSM/GPRS module***

60200810      Kamstrup 602. 3G GSM/GPRS module (GSM 8H 3G)***

60200840      Kamstrup 602. High Power Radio Router + 2 pulse inputs (VA, VB)

MULTICAL 602 RTC TOP MODULES

67020000      Kamstrup 602. Δenergy calculation + hourly data logger

67030000      Kamstrup 602. PQT limiter + hourly data logger*

67050000      Kamstrup 602. Data output + hourly data logger

67070000      Kamstrup 602. M-Bus**

67090000      Kamstrup 602. Δvolume calculation + hourly data logger

670A0000      Kamstrup 602. 2 pulse outputs (CE and CV) + scheduler + hourly data logger

670B0000      Kamstrup 602. 2 pulse outputs (CE and CV) + prog. data logger

6020C000      Kamstrup 602. 2 pulse outputs (CE and CV)

MULTICAL 402 SUPPLY MODULES

402-BATTERY       D – cell battery 4020002

402-230VAC 230v AC, supply module 4020007

402-24VAC 24v AC, supply module 4020008

MULTICAL 402 COMMUNICATION MODULES

402X10   Data and pulse intputs       402×10

402X11   Data and pulse outputs CE /CV 402X11

402X20   M-Bus with 2 pulse inputs 402X20

402X42   M-Bus with 2 pulse outputs CE/CV   402X21

402X40   Wireless M-Bus EU 868 MHz Mode 1       402×30

Radio EU 434 MHz int + ext ant NET0 + 2 pulse inputs 402×42

Radio EU 434 MHz int + ext ant NET0 + 2 pulse outputs CE/CV 402X43

Radio EU 434 MHz int + ext ant NET1 + 2 pulse inputs 402X44

Radio EU 434 MHz int + ext ant NET1 + 2 pulse outputs CE/CV 402X45

Radio SE 434 MHz int + ext ant NET0 + 2 pulse inputs 402X50

Radio SE 434 MHz int + ext ant NET0 + 2 pulse inputs 402X51

Radio SE 434 MHz int + ext ant NET0 + 2 pulse inputs 402X54

Radio SE 434 MHz int + ext ant NET0 + 2 pulse inputs 402X56

KAMSTRUPSTRUP 602 ULTRASonIC 65-S

DN150L 150mm Flanged PN25 Stainless Steel      65-S-FCCN-XXX   500mm       1500       150 300

DN150    150mm Flanged PN25 Stainless Steel      65-S-FDCN-XXX 500mm       2500       250 500

DN150H 150mm Flanged PN25 Stainless Steel      65-S-FECN-XXX   500mm       4000       400 800

DN150H 150mm Flanged PN25 Stainless Steel      65-S-FECP-XXX   500mm       4000       400 800

DN200    200mm Flanged PN25 Stainless Steel      65-S-FECR-XXX   600mm       4000       400 800

DN250    250mm Flanged PN25 Stainless Steel      65-S-FFCP-XXX    500mm       6000       600 1200

DN200H 200mm Flanged PN25 Stainless Steel      65-S-FFCR-XXX    600mm       6000       600 1200

KAMSTRUPSTRUP 602 ULTRASonIC HEAT METER

602DN15L     15mm/½ inch BSP c/w unions 65-5-CAAA-XXX 110mm   6     0.6       1.5

602DN20L     20mm/¾ inch BSP c/w unions   65-5-CAAD-XXX 130mm   6     0.6       1.5

602DN15       15mm/½ inch BSP c/w unions 65-5-CDAA-XXX 110mm   15   1.5       3.0

602DN20       20mm/¾ inch BSP c/w unions   65-5-CDAD-XXX 130mm   15   1.5       3.0

602DN15H     15mm/½ inch BSP c/w unions 65-5-CDAC-XXX 165mm   15   1.5       3.0

602DN20M    20mm/¾ inch BSP c/w unions   65-5-CDAE-XXX   165mm   15   1.5       3.0

602DN20H     20mm/¾ inch BSP c/w unions   65-5-CDAF-XXX   190mm   15   1.5       3.0

602DN20       20mm/¾ inch BSP c/w unions   65-5-CEAF-XXX   190mm   25   2.5       5.0

602DN25F     25mm/1 inch BSP c/w unions    65-5-CGAG-XXX 260mm   35   3.5       7.0

602DN25H     25mm/1 inch BSP c/w unions    65-5-CHAG-XXX 260mm   60   6.0       12.0

602DN40       40mm/1.1.2 inch BSP c/w unions      65-5-CJAJ-XXX    300mm   60       6.0   12.0

602DN20F     20mm Flanged PN25   65-5-CDBA-XXX 190mm   100 10.0 20.0

602DN20FH 20mm Flanged PN25     65-5-CEBA-XXX   190mm   15   1.5   3.0

602DN25F     25mm Flanged PN25   65-5-CGBB-XXX   260mm   25   2.5   5.0

602DN25FH 25mm Flanged PN25     65-5-CHBB-XXX 260mm   35   3.5   7.0

602DN40F     40mm Flanged PN25   65-5-CJBD-XXX   300mm   60   6.0   12.0

602DN50F     50mm Flanged PN25 Stainless Steel 65-5-CKCE-XXX   270mm   150       15.0 30.0

602DN65       65mm Flanged PN25 Stainless Steel 65-5-CLCG-XXX   300mm   250       25.0 50.0

602DN80       80mm Flanged PN25 Stainless Steel 65-5-CMCH-XXX 300mm   400       40.0 80.0

602DN100L 100mm Flanged PN25 Stainless Steel 65-5-FACL-XXX   360mm   600       60.0 120.0

602DN100     100mm Flanged PN25 Stainless Steel      65-5-FBCL-XXX    360mm       1000       100.0      200.0

KAMSTRUPSTRUP MULTICAL 402 HEAT METERS

402W1    15mm/½ inch BSP c/w unions 402W1    110mm   6     0.6   1.5

402W4    15mm/½ inch BSP c/w unions 402W4    110mm   15   1.5   3.0

402W5    15mm/½ inch BSP c/w unions 402W5    165mm   15   1.5   3.0

402W3    15mm/½ inch BSP c/w unions 402W3    190mm   6     0.6   1.5

402W7    20mm/¾ inch BSP c/w unions   402W7    130mm   15   1.5   3.0

402W9    20mm/¾ inch BSP c/w unions   402W9    190mm   15   1.5   3.0

402WA   20mm/¾ inch BSP c/w unions   402WA   130mm   25   2.5   5.0

402WB   20mm/¾ inch BSP c/w unions   402WB   190mm   25   2.5   5.0

402WD   25mm/1 inch BSP c/w unions    402WD   260mm   35   3.5   7.0

402WF    25mm/1 inch BSP c/w unions    402WF    260mm   60   6.0   12.0

402WG   25mm/1 inch BSP c/w unions    402WG   260mm   60   6.0   12.0

402WH   40mm/1.1.2 inch BSP c/w unions      402WH   300mm   100 10.0 20.0

402WJ    40mm Flanged PN25   402WJ    300mm   100 10.0 20.0

402WK   50mm Flanged PN25   402WK   270mm   150 15.0 30.0

402T1     15mm/½ inch BSP c/w unions 402W1    110mm   6     0.6   1.5

402T4     15mm/½ inch BSP c/w unions 402W4    110mm   15   1.5   3.0

402T5     15mm/½ inch BSP c/w unions 402W5    165mm   15   1.5   3.0

402T3     15mm/½ inch BSP c/w unions 402W3    190mm   6     0.6   1.5

402T7     20mm/¾ inch BSP c/w unions   402W7    130mm   15   1.5   3.0

402T9     20mm/¾ inch BSP c/w unions   402W9    190mm   15   1.5   3.0

402TA     20mm/¾ inch BSP c/w unions   402WA   130mm   25   2.5   5.0

402TB     20mm/¾ inch BSP c/w unions   402WB   190mm   25   2.5   5.0

402TD    25mm/1 inch BSP c/w unions    402WD   260mm   35   3.5   7.0

402TF     25mm/1 inch BSP c/w unions    402WF    260mm   60   6.0   12.0

402TG    25mm/1 inch BSP c/w unions    402WG   260mm   60   6.0   12.0

402TH    40mm/1.1.2 inch BSP c/w unions      402WH   300mm   100 10.0 20.0

402TJ     40mm Flanged PN25   402WJ    300mm   100 10.0 20.0

402TK     50mm Flanged PN25   402WK   270mm   150 15.0 30.0
